ARTHERMO ARTH096 溫度控制器
規格介紹:ARTHERMO ARTH096 溫度控制器
詳細介紹:
溫度範圍 : 0/40°C
Encased thermostat 0/40°C with capillary mm 1500, particularly suitable for temperature control in air-conditioning. Easy wall installation with only two screw dowels, included in the box.
TECHNICAL DETAILS
| Switching capacity | C-1 15(2,5)A 400 VAC |
| Differential | 4°C ± 2K |
| Product life | 100.000 switching cycles |
| Minimum current | 200 mA without gold contact |
| Insulation resistance | > 100 Mohm |
| Max temp.around case | T110°C |
| Max temp.around bulb | +15% maximum switching value |
| Dielectric strength | AC 2000V 1 min. |
| Connection | Faston 6,3x0,8 terminals |
| European approval | ENEC 03 |
| Protection class | IP40 |
※ 此款溫度控制器具有ENEC認證
更多商品
ARTHERMO ARTH097 溫度控制器
溫度範圍: 0/90°C Boxed Thermostat 0/90°C capillary mm 1500, particularly suitable for temperature control on heating systems, circulation pumps, burners and heaters. Easy wall installation with only two screw dowels, included in the boxTECHNICAL DETAILS Switching capacity C-1 15(2,5)A 400 VACC-2 2,5(0,4)A 400 VAC Differential 4°C ± 2,5K Product life 100.000 Switching cycles Minimum current 200mA without gold contact Insulation resistance > 100 Mohm Max temp.around case T110°C Max temp.around bulb +15% maximum switching value Dielectric strength AC2000 V 1 min. Connection 6,3x0,8 terminals European approval ENEC 03 Protection class IP40 ※ 此款溫度控制器具有ENEC認證
ARTHERMO ARTH300 溫度控制器
溫度範圍: 0/90°C Boxed thermostat 0/90°C fitted with heat resistant band tie for fixing; particularly suitable for temperature control on heating systems.Projected for direct application on pipes with diameter between 15 and 80 mm. Fixing through a heat-resistant band tie in nylon, included in the box.TECHNICAL DETAILS Switching capacity C-1 15(2,5)A 400 VACC-2 2,5(0,4)A 400 VAC Differential 4°C ± 2,5K Product life 100.000 switching cycles Minimum current 200 mA without gold contact Insulation resistance > 100 Mohm Max temp.around case T 110°C Max temp.around bulb + 15% maximum switching value Dielectric strength AC 2000 V 1 min. Connection Faston 6,3 x 0,8 mm terminals European approval ENEC 03 Protection class IP40 ※ 此款溫度控制器具有ENEC認證
ARTHERMO ARTH100 溫度控制器
溫度範圍: 0/90°C Immersion adjustable thermostat liquid filled operating , SPDT contacts , with waterproof protection pocket 1/2" X 100 mm. Suitable for automatic adjustment of heating system, burners and pumps.THERMOSTAT TECHNICAL SPECIFICATIONS Switching capacity C-1 15(2,5)A 400 VAC C-2 2,5(0,4)A 400 VAC Life of product 100.000 switching cycles Adjustable range °C 0/90°C Insulation resistant >100Mohm Max°C around body T110°C Max°C around bulb +15% switching value Dielectric strength AC2000V 1 min. Connection Faston 6,3 X 0,8 Approvals ENEC 03 Degree protection IP40 ※ 此款溫度控制器具有ENEC認證
ARTHERMO ARTH201 溫度控制器
Safety temperature: 100°C ± 5°CArthermostat design. safety type, in ABS for pipe direct contact through heat-resistant band tie ( included ). Particularly suitable for temperature control of water in heating system. Manual reset.TECHNICAL DETAILS Switching capacity C-1 1A 250 VACC-2 16A 250 VAC Safety 100°C ± 5°C Product life 6.000 switching cycles Minimum current 200 mA without gold contact Insulation resistance > 100 Mohm Max temp.around case T 150°C Max temp. around bulb +15% maximum switching value Dielectric strength AC 2000 V 1 min. Connection Faston 6,3x0,8 terminals European approvals VDE inside thermostat Protection class IP40
ARTHERMO ARTH202 溫度控制器
Safety temperature: 100°C ± 5°C Arthermostat design. safety type, in ABS with brass pocket 1/2"G X 100 mm. Particularly suitable for temperature control of water in heating system. Manual reset.THERMOSTAT TECHNICAL SPECIFICATION Switching value C-1 1A 250VACC-2 16A 250VAC Life of product 6000 switching value Safety 100°C ± 5°C Insulation resistant >100Mohm Max °C around body T150°C Max °C around bulb T130°C Dielectric strenght AC 2000V 1 min Connection 6,3 x 0,8 European approvals VDE thermostat inside Degree of protection IP40
ARTHERMO ARTH401 溫度控制器
溫度範圍: 0/90°C Double immersion boxed thermostat with brass pocket 1/2"G X 100 mm. Two adjustable thermostatats 0/90°C. Particularly suitable for temperature control of water in heating system, burners and pumps.TECHNICAL SPECIFICATION ADJUSTABLE THERMOSTATS Switching capacity C-1 15(2,5)A 400 VACC-2 2,5(0,4)A 400VAC Life of product 100.000 switching cycles Range 0/90°C Insulation resistant >100Mohm Max °C around body T110°C Max °C around bulb +15% Switching value Dielectric strenght AC2000V 1min Connection Faston 6,3X0,8 European approvals ENEC03 thermostats inside Degree of protection IP40
ARTHERMO ARTH400 溫度控制器
溫度範圍: 0/90°C Safety temperature: 100°C ± 5°CDouble boxed thermostat, ARTHERMOSTAT line with brass pocket 1/2"C x 100 mm. Adjustable thermostat 0/90°C and safety thermostat 100°C.Particularly suitable for temperature control of water in heating system. Manual reset.REGULATION THERMOSTAT SPECIFICATIONS Switching capacity C-1 15(2,5)A 400VACC-2 2,5(0,4)A 400VAC Life of products 100.000 switching cycles Range 0/90°C Insulation resistant >100Mohm Max °C around body T110°C Max °C around bulb +15% F.S. Dielectric strenght AC2000V 1 min. Connection Faston 6,3 x 0,8 European approvals ENEC03 thermostat inside Degree of protection IP40 SAFETY THERMOSTAT SPECIFICATIONS Switching capacity C-1 1A 250VACC-2 16A 250VAC Life of product 6000 switching cycles Safety 100°C ± 5°C Insulation resistance >100Mohm Max °C around body T150°C Max °C around bulb T130°C Dielectric strenght AC2000V 1min. Connection Faston 6,3 x 0,8 European approval VDE thermostat inside Degree of protection IP40
ARTHERMO ARTH090 溫度控制器
溫度範圍: 0/40°C Athermostat design in ABS with side spiral bulb. Particularly suitable for temperature control in refrigeration and air conditioning sectors. Easy wall installation with only two screw dowels (included).TECHNICAL DETAILS Switching capacity C-1 15(2,5)A 400 VAC C-2 2,5(0,4)A 400 VAC Differential 2°C ± 1,5K Product life 100.000 switching cycles Minimum current 200 mA without gold contact Insulation resistance > 100 Mohm Max.temp.around case T110°C Max.temp.around bulb +15% maximum switching value Dielectric strenght AC 2000V 1 min. Connection Faston 6,3 x 0,8 European approvals ENEC03 - inside thermostats Protection class IP40
